Products > City Bus Terminal
TG-T8
TG-T8
Product Name: Intelligent Vehicle Terminal
Product model: TG-T8
Industrial design with support for local and remote updates
GPS/Beidou dual mode module
Good waterproof, shockproof and electromagnetic interference resistance
7 inch full color HD TFT_LCD screen (800*480)
Support 8-channel D1 (720*576) video recording (H.264 compression)
In case of accidental power failure, it can still work for 6 seconds to ensure data integrity.
Watermarking technology to prevent data tampering, to ensure the authenticity and legal effect of the video
Hard disk system uses data such as hydraulic shock absorption, electronic protection and software abnormal recovery to ensure data security
Adopt dynamic rate coding technology to adapt to the dynamic change of 3G/4G network bandwidth to ensure monitoring video stream consistency
Product description
|
Equipment detailed parameters |
||
|
Name |
Device parameters |
Performance |
|
Work performance |
Operating Voltage |
DV 8-36V |
|
Operating temperature |
-20℃～ +70℃ |
|
|
environment humidity |
Relative humidity of 90% to 95% (no condensation) meets the needs of high temperature and high humidity in summer; |
|
|
monitor rate |
﹤60W |
|
|
Storage performance
|
Storage performance |
PAL/NTSC |
|
Power failure protection |
H.264 |
|
|
Self-connect function |
720P/960H/D1/CIF |
|
|
Data replacement |
720P/D1/CIF |
|
|
Operating screen performance |
Waterproof and dustproof |
Manual, alarm |
|
Number of buttons |
18 |
|
|
Button life |
More than 40,000 times |
|
|
Peripheral communication |
CAN |
2 way CAN |
|
RS485 |
2 way 485 |
|
|
RS232 |
2 way 232 |
|
|
Switching support |
I/O Switch |
3-way gating, reversing, braking, left and right direction, cash box, speed sensor |
|
Input and output support |
Input and output support |
2-channel analog acquisition, 2-way button (alarm or passenger), 2-channel output (off oil, power off), 12V 1A output |
